Hyundai Elantra: Front Door / Front Door Inside Handle Repair procedures

Hyundai Elantra AD (2016-2020) Service Manual / Body (Interior and Exterior) / Front Door / Front Door Inside Handle Repair procedures

Replacement

1.	Remove the front door trim. (Refer to Front Door - "Front Door Trim")

2.	After loosening the mounting screws, remove the front door inside handle (A).

To intall, reverse the removal procedure.

•	Make sure the door locks / unlocks and opens / closes properly.

•	Replace any damaged clips (or pin-type retainers).
