Front Hub / Knuckle Components and Components LocationHyundai Elantra AD (2016-2020) Service Manual: Components and Components Location
Components
1. Glass panel assembly2. Deflector3. Motor assembly4. Spring base assembly5. Plate rail assembly6. Guide rail assembly7. Drip link rail8. Seal tape9. Frame sub assembly10. Stopper11. Sunshade assembly12. Drip rail assembly
...
Hyundai Elantra AD (2016-2020) Service Manual: AUX jack Repair procedures
Removal
1.
Disconnect the battery (-) terminals.
2.
Remove the floor console assembly.
(Refer to Body - "Floor Console Assembly")
3.
Remove the multimedia jack (A) from the console under cover after releasing the fixed hooks (B).
Installation
1.
Connect the multimedia jack connecto ...
