Hyundai Elantra AD (2016-2020) Service Manual: Description and Operation
Description
Body Control Module (BCM) function
NoItemDescription1Washer Linked Wiper
-
If the washer switch is pressed ON for 0.06~0.2 second with
the vehicle mode in IGN2, the wiper relay is turned ON 0.3±0.1 second
after washer switch ON, and then the wiper relay is turned OFF 0.7Â ...
Hyundai Elantra AD (2016-2020) Service Manual: Multimedia Jack Repair procedures
Removal
1.
Disconnect the battery (-) terminals.
2.
Remove the floor console assembly.
(Refer to Body - "Floor Console Assembly")
3.
Remove the multimedia jack (A) from the console under cover after releasing the fixed hooks (B).
Installation
1.
Connect the multimedia jack connecto ...
